Product information
ABNOX drum pumps with 2-hand control are used for the process-safe delivery of medium to high viscosity lubricants from original containers (from cartridges to 180 kg containers).
Thanks to the pneumatic tracking of the follower plate, the lubricant is optimally fed to the suction pipe at every filling level, even with conical containers or drums with beads.
The pump switches off automatically shortly before complete emptying, thus preventing air from being sucked in.
This pump is ideally suited as feed pumps for dosing stations or dosing valves in assembly lines and at workplaces.
For all overseas exports the ABNOX Drum Pump AXFP4 must be packed in a plywood folding box according to ISPM-15 standard (Dimension 97x67x155 cm / Art.-No. 0003382).
We are happy to calculate the follower plate for you.
To come up with the right size we need the following:
- internal top-diameter
- internal bottom-diameter
- container height
Container internal dia. [mm]
550- 580
Container height [mm]
870
Suction tube dia. [mm]
32
Input medium specification
Lubricants up to NLGI 4 / 1'000'000 m Pa s
Delivery rate at pump outlet [cm3/min]
1720
Delivery rate per double stroke [cm3]
16
Min. / max. workingpressure medium inlet [bar]
4/10
Working pressure medium outlet at pneumatic operating pressure 6 bar [bar]
60
Working pressure medium outlet at pneumatic operating pressure 10 bar [bar]
100
Connection internal thread
1/4'' BSP
Connection medium outlet external thread
1/4'' BSP
Max. air consumption [l/min.]
150
Optimum pneumatic operatingpressure [bar]
6
Min. / max. pneumatic operating pressure [bar]
4/10
Pneumatic connection internal thread
1/4'' BSP
Min. / max. operatingtemperature [°C]
10/40
