Product information
ABNOX MAXI double high-performance Drum Pumps with 2-hand Control and high delivery capacity are used for the reliable pumping of medium to high-viscosity lubricants from original containers.
After the first drum has been completely emptied (empty signal), the Pump automatically switches to the second drum. This means that drums can be changed quickly, cleanly and conveniently without interrupting the grease supply.
In the Medium Operating Panel the actual state of the two Pumps is indicated by coloured Indicators (Pump ready, Pump at work).
| Model | Ratio | Container size | Article No. |
|---|---|---|---|
2xAXFP3-M20 | 20:1 MAXI | 2x up to 50 kg | 4645500 |
2xAXFP3-M40 | 40:1 MAXI | 2x up to 50 kg | 4645600 |
| Option | Description | Quantity | Article No. |
|---|---|---|---|
| G | Acoustic refill and empty Signal | 2 pieces | 0010211 |
| L | Acoustic container empty Signal | 2 pieces | 0010209 |
F00 | Electrical remote on/off Switching | 2 pieces | 0013084 |
Z00 | Electrical Pressure Relief of the cylinders | 2 pieces | 0014362 |
| N00 | Electrical refill and empty Signal | 4 pieces | 0001220 |
FN0 | Electrical remote on/off Switching with Electrical refill and empty Signal | 2 Pieces
and
4 Pieces | 0013084
and
0001220 |
F0Z | Electrical remote on/off Switching with Electrical Pressure Relief of the cylinders | 2 Pieces
and
2 Pieces | 0013084
and
0014362 |
FNZ | Electrical remote on/off Switching with Electrical refill and empty Signal and Electrical Pressure Relief of the cylinders | 2 Pieces
and
4 Pieces
and
2 Pieces | 0013084
and
0001220
and
0014362 |
0NZ | Electrical refill and empty Signal with Electrical Pressure Relief of the cylinders | 4 Pieces
and
2 Pieces | 0001220
and
0014362 |
| AB | Connection Piece 1/2'' BSP with Gauge 400 bar and Ball Valve for air vent | 2 pieces | 4082003 |
| DG | Pressure Release with Connection Piece | 2 pieces | 4082009 |
| SF | Pedestal | 2 pieces | 0008548 |
| LR | 4x Guide Rollers/Swivel Castor | 2 pieces | 0008569 |
| Model | Ratio | Seal Kit | Article No. |
|---|---|---|---|
2xAXFP3-M20 | 20:1 MAXI | Air Motor | 0006907 |
2xAXFP3-M40 | 40:1 MAXI | Air Motor | 0006907 |
2xAXFP3-M20 | 20:1 MAXI | Suction System | 0002968 |
2xAXFP3-M40 | 40:1 MAXI | Suction System | 0002970 |
For all overseas shipments, the ABNOX Twin-Drum Pump 2xAXFP3-M is packed in two plywood folding boxes according to ISPM standard 15.
| Model Drum Pump | Dimension Plywood folding box | Article No. Plywood folding box |
|---|---|---|
2xAXFP3-Mxx | 80 x 60 x 145 cm | 0003001 |
