Product information
Pressure Reducing Valve Set DR3 (V2010) 0 - 10 bar for all Grease Supply Systems with additional Connection for a Metering Valve.
With this Pressure Reducing Valve 0 - 10 bar may be used to control the flow rate and max. pressure of Air-operated Grease Pump.
Range of adjustment: 0.05 up to 8.5 bar
Volume flow rate: 800 l/min.
Set consists of:
- 1 Pressure Reducing Valve with Gauge 0-10 bar
- 1 Connector Splitter 1/4" BSP
- 1 ABNOX AX-100 safety Air Coupling with female plug for Hose dia. 6/4 mm
Operating pressure [bar]
10
Connection external thread
1/4'' BSP (Output air)
Min. / max. operatingtemperature [°C]
-5/60
