Rotary Dosing Unit AXDV-R1-O (Operation Medium Oil)

Article-No.	0009639 / 0009640 / 0009641 / 0009642 / 0009643
Modell	AXDV-R1-O
Design	with Vario-Metering Valve AXDV-V1
Version	for Operation Medium Oil

Enquire about product

Product information

This Rotary Dispenser is suitable for applications with oil (-O).

AXDV R1 D08

AXDV R1 D16

Model	Plate diameter	Lance length	Article No.
AXDV-R1-O-D08-L050-V1	8 mm	50 mm	0009639
AXDV-R1-O-D08-L140-V1	8 mm	140 mm	0009640
AXDV-R1-O-D16-L010-V1	16 mm	10 mm	0009641
AXDV-R1-O-D16-L100-V1	16 mm	100 mm	0009642
AXDV-R1-O-D16-L160-V1	16 mm	160 mm	0009643


Centrifugal plate diameter [mm]	8	16
Lance length [mm]	50, 140	10, 100, 160
Speed [rpm]	3'000 - 6'000	3'000 - 6'000
Operation medium	Oil	Oil
Max. working pressure medium inlet [bar]	Depending on the material supply used	Depending on the material supply used
Connection medium inlet external thread	1/8“ BSP	1/8“ BSP
Frequency [Hz]	50	50
Voltage [V DC]	230	230
Min. / max. operating temperature [°C]	10 / 40	10 / 40

Assembly Instruction

pdf
